4-Bolt Flange HT750 Carbon Sleeve Bearing

Description
Product Filtering

4-Bolt Flange HT750 Carbon Sleeve Bearing

  • Ni Plated Steel Ring
  • HT750 Bearing Grade Carbon
  • Service: -40 °F to 750 °F
  • No. 35 Cast Iron Housing
  • Maintenance Free
  • Coefficient of Friction: ~0.2
Self-aligning, maintenance-free, carbon-graphite sleeve in a nickel-plated carbon steel backing ring, mounted in a cast iron housing. It uses our proven design that maintains the self-aligning capability of the bearing by preventing oxidation of the spherical surfaces and our tight-grained graphite that resists seizure in outdoor intermittent service applications.

2D and 3D files are available for download For drawings and 3D models, click on a part number.

checkbox icon Checked items ship within 24 hours. Unmarked items typically ship in 1-4 weeks. Any items listed as "Request For Quote" (RFQ) usually ship in 3-6 weeks.

Bore (in) Part # A (in) B (in) C (in) D (in) F (in) H (in) J (in) L (in) Bearing Insert Static (lb) Weight(lbs)
0.506 4BF204HT750-050 1.5 3.386 1.116 2.52 0.453 0.512 0.131 1.359 HR204-HT7-050 1100 1.5
0.632 4BF204HT750-062 1.5 3.386 1.116 2.52 0.453 0.512 0.131 1.359 HR204-HT7-062 1100 1.5
0.757 4BF204HT750-075 1.5 3.386 1.116 2.52 0.453 0.512 0.131 1.359 HR204-HT7-075 1100 1.5
0.597 4BF204HT750-15 1.5 3.386 1.116 2.52 0.453 0.512 0.131 1.359 HR204-HT7-15 1100 1.5
0.794 4BF204HT750-20 1.5 3.386 1.116 2.52 0.453 0.512 0.131 1.359 HR204-HT7-20 1100 1.5
0.882 4BF205HT750-088 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.557 HR205-HT7-088 1500 1.9
0.945 4BF205HT750-094 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.557 HR205-HT7-094 1500 1.9
1.007 4BF205HT750-100 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.557 HR205-HT7-100 1500 1.9
0.991 4BF205HT750-25 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.557 HR205-HT7-25 1500 1.9
