Stainless Steel, Eccentric Collar, Ball Bearing Insert: SNA204-08

Stainless Steel, Eccentric Collar, Ball Bearing Insert: SNA204-08

SNA Stainless, Eccentric Collar, Ball Bearing Insert
RFQ
CAD
MANUAL
Specifications:
Attribute nameAttribute value
SeriesSNA
Bore (in)0.5
D (in)1.854
B (in)1.3465
B1 (in)1.725
C (in)0.6693
S (in)0.6732
B2 (in)0.5315
h (in)0.1475
d1 (in)1.311
G (in)0.1969
ds1/4-28 UNF
C (lb)2740
C0 (lb)1600
Weight(lbs)0.6
Code103277
PackageQTY1
UOMEA
Dynamic Capacity (lb)2740
Static Capacity (lb)1600
Tmax (F)248
Tmin (F)-10
