1-3/4" S2000 Expansion Piloted Flange Heavy Duty Bearing
Print Page
Heavy Duty S2000 Piloted Flange: S2-FCF-175RSE
Heavy Duty S2000 Piloted Flange: S2-FCF-175RSE
S2000 Expansion Piloted Flange Mounted Spherical Roller Bearing
$496.31
Qty:
EA
checkbox icon
This item typically ship in 1-4 weeks.
CAD
PDF
DWG
STP
TDS
MANUAL
Specifications:
metric
Attribute name
Attribute value
Construction
Piloted Flange
Type
Expansion
Collar
Single Locking Collar
Shaft Size
1-3/4"
Dismount Thread
5/16-18 UNC
A (mm)
155.6
B (mm)
63.5
C (mm)
12.7
D (mm)
66.7
Bolt
M12
G (mm)
41.9
H (mm)
22.2
K (mm)
40.5
L (mm)
73.2
M (mm)
92
Z (mm)
108
Co (lb)
21360
Weight(lbs)
8
Code
105440
PackageQTY
1
UOM
EA
Series
S2000
Bore (mm)
44.45
E (mm)
130.2
T (mm)
82.4
X (mm)
6
C (lb)
17980
Max RPM-Triple Lip Seal
2425
Max RPM-PTFE Seal
3360
Max RPM-Metal Labyrinth Seal
3360
A self-aligning spherical roller bearing mounted in ductile iron housing with independent set screw shaft locking collars makes this one of the most rugged and easy-to-install mounted bearings available. Expansion units allow for axial shaft growth. Request a quote for options such as end covers, special seals, and custom lubrication for improved performance and increased range of service temperatures.
