Home
>
Heavy Duty Mounted Bearings
>
S2000 Mounted Spherical Roller Bearings
>
30mm S2000 Non Expansion 4 Bolt Flange Heavy Duty Bearing
Print Page
Heavy Duty S2000 4 Bolt Flange: S2-4BF-30MMRSN
Heavy Duty S2000 4 Bolt Flange: S2-4BF-30MMRSN
S2000 Non Expansion 4 Bolt Flange Mounted Spherical Roller Bearing
$440.36
Qty:
EA
checkbox icon
This item typically ship in 1-4 weeks.
CAD
PDF
DWG
STP
TDS
MANUAL
Specifications:
metric
Attribute name
Attribute value
Construction
4-Bolt Flange
Type
Non-Expansion
Collar
Single Locking Collar
Shaft Size
30mm
A (mm)
117.5
B (mm)
57.2
C (mm)
75
D (mm)
60
E (mm)
89.81
Bolt
M16
H (mm)
19
J (mm)
98
K (mm)
127
L (mm)
69.9
Co (lb)
20230
Weight(lbs)
7
Code
105367
PackageQTY
1
UOM
EA
Series
S2000
Bore (mm)
30
C (lb)
17540
Max RPM-Triple Lip Seal
2750
Max RPM-PTFE Seal
3600
Max RPM-Metal Labyrinth Seal
3600
A self-aligning spherical roller bearing mounted in ductile iron housing with independent set screw shaft locking collars makes this one of the most rugged and easy-to-install mounted bearings available. Non-expansion units prevent axial movement. They are typically placed closest to the drive. Request a quote for options such as end covers, special seals, and custom lubrication for improved performance and increased range of service temperatures.
