High Temperature Piloted Flange: HUCFCF209-27KX

High Temperature Piloted Flange: HUCFCF209-27KX

HU-KX, Piloted Flange
$371.79
CAD
DATA SHEET
MANUAL
Specifications:
Attribute nameAttribute value
ConstructionPiloted Flange
Bore (in)1.6875
H (in)6.1417
L (in)5.126
J (in)0.8661
A2 (in)0.4724
A1 (in)0.4724
H2 (in)1.455
A (in)4.252
N (in)0.5315
E (in)1.937
S (in)0.748
B (in)1.189
Bolt7/16
Bearing InsertHUC209-27KX
HousingFCF209
Weight(lbs)6.2
Code102925
PackageQTY1
UOMEA
SeriesHU-KX
H1 (in)0.2165
