High Temperature Piloted Flange: HUCFCF205-14KX

High Temperature Piloted Flange: HUCFCF205-14KX

HU-KX, Piloted Flange
$206.33
CAD
DATA SHEET
MANUAL
Specifications:
Attribute nameAttribute value
ConstructionPiloted Flange
Bore (in)0.875
H (in)4.371
L (in)3.626
J (in)0.8661
A2 (in)0.2362
A1 (in)0.3937
H2 (in)1.225
A (in)3
N (in)0.455
E (in)1.3386
S (in)0.563
B (in)0.7756
Bolt5/16
Bearing InsertHUC205-14KX
HousingFCF205
Weight(lbs)2.6
Code102913
PackageQTY1
UOMEA
SeriesHU-KX
H1 (in)0.4331
