Split 4-Bolt Flange HT750 Carbon Sleeve Bearing

Description
Product Filtering

Split 4-Bolt Flange HT750 Carbon Sleeve Bearing

  • Split Ni Plated Steel Ring
  • HT750 Bearing Grade Carbon
  • Service: -40 °F to 750 °F
  • Split Ductile Iron Housing
  • Maintenance Free
  • Coefficient of Friction: ~0.2
Fully split, self-aligning, maintenance-free, carbon-graphite sleeve in a nickel-plated carbon steel backing ring mounted in a split ductile iron housing. It is dimensionally interchangeable with a solid mounted bearing. It uses our proven design that maintains the self-aligning capability of the bearing by preventing oxidation of the spherical surfaces and our tight-grained graphite that resists seizure in outdoor intermittent service applications.

2D and 3D files are available for download For drawings and 3D models, click on a part number.

checkbox icon Checked items ship within 24 hours. Unmarked items typically ship in 1-4 weeks. Any items listed as "Request For Quote" (RFQ) usually ship in 3-6 weeks.

Bore (in) Part # A (in) B (in) C (in) D (in) F (in) H (in) J (in) L (in) Bearing Insert Static (lb) Weight(lbs)
0.882 4BF205SHT750-088P 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.815 SSP205-HT7-088 1500 2
0.945 4BF205SHT750-094P 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.815 SSP205-HT7-094 1500 2
1.007 4BF205SHT750-100P 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.815 SSP205-HT7-100 1500 2
0.991 4BF205SHT750-25P 1.17 3.74 1.183 2.756 0.453 0.512 0.12 1.815 SSP205-HT7-25 1500 2
1.132 4BF206SHT750-112P 1.232 4.252 1.325 3.268 0.453 0.563 0.14 2.23 SSP206-HT7-112 2100 3.4
1.195 4BF206SHT750-118P 1.232 4.252 1.325 3.268 0.453 0.563 0.14 2.23 SSP206-HT7-118 2100 3.4
1.188 4BF206SHT750-30P 1.232 4.252 1.325 3.268 0.453 0.563 0.14 2.23 SSP206-HT7-30 2100 3.4
1.257 4BF207SHT750-125P 1.289 4.66 1.393 3.622 0.512 0.61 0.54 2.339 SSP207-HT7-125 3200 4
1.446 4BF207SHT750-144P 1.289 4.66 1.393 3.622 0.512 0.61 0.54 2.339 SSP207-HT7-144 3200 4
