Sealed Silicon Nitride Deep Groove Ceramic Ball Bearing: 6318-SN2RS

Sealed Silicon Nitride Deep Groove Ceramic Ball Bearing: 6318-SN2RS

Deep Groove, Single Row, Ceramic, Sealed, Si3N4
$5,174.35
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
SeriesSi3N4
SealsSeals
Bore (mm)90
D (mm)190
B (mm)43
d1 (mm)121
D2 (mm)164
C (lb)8037
C0 (lb)6014
Nmax (RPM)3010
Weight(lbs)4.34
Code102045
PackageQTY1
UOMEA
C (kN)35.75
C0 (kN)26.75
Ra (mm)2.5
Da (mm)176
damin (mm)104
kr30
ka0.5
fo13
r (mm)3
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
