1200°C Silicon Carbide Deep Groove Ball Bearing: 6318-SCF

1200°C Silicon Carbide Deep Groove Ball Bearing: 6318-SCF

Deep Groove, Full Complement, Single Row, High Temp 1200 C,SiC
$3,788.37
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction2192F Open
Bore (mm)90
D (mm)190
B (mm)43
d1 (mm)121
D2 (mm)164
C (lb)6430
C0 (lb)4811
Nmax (RPM)1806
Weight(lbs)4.34
Code102043
PackageQTY1
UOMEA
SeriesSiC
C (kN)28.6
C0 (kN)21.4
Ra (mm)2.5
Da (mm)176
damin (mm)104
kr30
ka0.5
fo13
r (mm)3
SealsNone
Clearance0.0005"
Tmax (F)2192
Tmin (F)-112
DutyHigh Temperature
