Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6318-SC2RS

Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6318-SC2RS

Deep Groove, Single Row, Ceramic, Sealed, SiC
$6,100.91
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
SeriesSiC
SealsSeals
Bore (mm)90
D (mm)190
B (mm)43
d1 (mm)121
D2 (mm)164
C (lb)6430
C0 (lb)4811
Nmax (RPM)2580
Weight(lbs)4.34
Code102042
PackageQTY1
UOMEA
C (kN)28.6
C0 (kN)21.4
Ra (mm)2.5
Da (mm)176
damin (mm)104
kr30
ka0.5
fo13
r (mm)3
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
