800°C Silicon Nitride Deep Groove Ball Bearing: 6311-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6311-SNF

Deep Groove, Full Complement, Single Row, High Temperature 800 °C Si3N4 Ball Bearing
$925.02
This product has a minimum quantity of 3
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)55
D (mm)120
B (mm)29
d1 (mm)75.3
D2 (mm)104
C (lb)4024
C0 (lb)2529
Nmax (RPM)3283
Weight(lbs)1.19
Code101956
PackageQTY1
UOMEA
C (kN)17.9
C0 (kN)11.25
Ra (mm)2
Da (mm)109
damin (mm)66
kr30
ka0.5
fo13
r (mm)2
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSi3N4
