800°C Silicon Nitride Deep Groove Ball Bearing: 6309-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6309-SNF

Deep Groove, Full Complement, Single Row, High Temp 800 C,Si3N4
$650.13
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)45
D (mm)100
B (mm)25
d1 (mm)62.2
D2 (mm)86.7
C (lb)2979
C0 (lb)1798
Nmax (RPM)3920
Weight(lbs)0.71
Code101931
PackageQTY1
UOMEA
SeriesSi3N4
C (kN)13.25
C0 (kN)8
Ra (mm)1.5
Da (mm)91
damin (mm)54
kr30
ka0.5
fo13
r (mm)1.5
SealsNone
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
