Sealed Zirconium Oxide Deep Groove Ceramic Ball Bearing: 6307-ZO2RS

Sealed Zirconium Oxide Deep Groove Ceramic Ball Bearing: 6307-ZO2RS

Deep Groove, Single Row, Ceramic, Sealed, ZrO2
$218.17
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
SeriesZrO2
SealsSeals
Bore (mm)35
D (mm)80
B (mm)21
d1 (mm)49.6
D2 (mm)69.2
C (lb)2253
C0 (lb)1302
Nmax (RPM)6000
Weight(lbs)0.76
Code101909
PackageQTY1
UOMEA
C (kN)10.02
C0 (kN)5.79
Ra (mm)1.5
Da (mm)71
damin (mm)44
kr30
ka0.5
fo13
r (mm)1.5
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
