400°C Zirconium Oxide Deep Groove Ball Bearing: 6303-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6303-ZOF

Deep Groove, Full Complement, Single Row, High Temperature 400 °C ZrO2 Ball Bearing
$84.70
This product has a minimum quantity of 5
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)17
D (mm)47
B (mm)14
d1 (mm)24
D2 (mm)39.7
C (lb)917
C0 (lb)448
Nmax (RPM)7560
Weight(lbs)0.19
Code270066
PackageQTY1
UOMEA
C (kN)4.08
C0 (kN)1.995
Ra (mm)1
Da (mm)41.4
damin (mm)22.6
kr30
ka0.5
fo12
r (mm)1
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesZrO2
