400°C Zirconium Oxide Deep Groove Ball Bearing: 6302-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6302-ZOF

Deep Groove, Full Complement, Single Row, High Temperature 400 °C ZrO2 Ball Bearing
$79.57
This product has a minimum quantity of 5
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)15
D (mm)42
B (mm)13
d1 (mm)21.1
D2 (mm)36.3
C (lb)769
C0 (lb)368
Nmax (RPM)8400
Weight(lbs)0.14
Code101848
PackageQTY1
UOMEA
C (kN)3.42
C0 (kN)1.635
Ra (mm)1
Da (mm)36.4
damin (mm)20.6
kr30
ka0.5
fo12
r (mm)1
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesZrO2
