800°C Silicon Nitride Deep Groove Ball Bearing: 6300-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6300-SNF

Deep Groove, Full Complement, Single Row, High Temp 800 C,Si3N4
$74.18
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)10
D (mm)35
B (mm)11
d1 (mm)15.7
D2 (mm)28.7
C (lb)455
C0 (lb)194
Nmax (RPM)13230
Weight(lbs)0.05
Code270062
PackageQTY1
UOMEA
SeriesSi3N4
C (kN)2.025
C0 (kN)0.863
Ra (mm)0.6
Da (mm)30.8
damin (mm)14.2
kr30
ka0.25
fo11
r (mm)0.6
SealsNone
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
