Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6220-SC2RS

Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6220-SC2RS

Deep Groove, Single Row, Ceramic, Sealed, SiC
$5,590.15
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
SeriesSiC
SealsSeals
Bore (mm)100
D (mm)180
B (mm)34
d1 (mm)118
D2 (mm)160
C (lb)5485
C0 (lb)4186
Nmax (RPM)2580
Weight(lbs)2.75
Code101774
PackageQTY1
UOMEA
C (kN)24.4
C0 (kN)18.62
Ra (mm)2
Da (mm)169
damin (mm)111
kr25
ka0.5
fo14
r (mm)2.1
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
