1200°C Silicon Carbide Deep Groove Ball Bearing: 6219-SCF

1200°C Silicon Carbide Deep Groove Ball Bearing: 6219-SCF

Deep Groove, Full Complement, Single Row, High Temperature 1200 °C SiC Ball Bearing
$4,139.87
This product has a minimum quantity of 3
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction2192F Open
Shaft Size95mm
D (mm)170
B (mm)32
d1 (mm)112
D2 (mm)151
C (lb)4901
C0 (lb)3682
Nmax (RPM)1890
Weight(lbs)2.28
Code101751
PackageQTY1
UOMEA
Bore (mm)95
C (kN)21.8
C0 (kN)16.38
Ra (mm)2
Da (mm)159
damin (mm)106
kr25
ka0.5
fo14
r (mm)2.1
Clearance0.0005"
Tmax (F)2192
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSiC
MaterialSiC
Designed to handle a combination of radial and axial forces at a range of speeds, temperatures, and environments for an extended period with minimal friction. Operation above the continuous duty temperature will reuslt in a loss of clearnce and reduce bearing life.
