400°C Zirconium Oxide Deep Groove Ball Bearing: 6217-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6217-ZOF

Deep Groove, Full Complement, Single Row, High Temp 400 C, ZrO2
$1,822.32
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)85
D (mm)150
B (mm)28
d1 (mm)106
D2 (mm)134
C (lb)5665
C0 (lb)4175
Nmax (RPM)2100
Weight(lbs)2.88
Code101730
PackageQTY1
UOMEA
SeriesZrO2
C (kN)25.2
C0 (kN)18.57
Ra (mm)2
Da (mm)141
damin (mm)94
kr25
ka0.5
fo15
r (mm)2
SealsNone
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
