Naked Silicon Nitride Deep Groove Ceramic Ball Bearing: 6216-SN

Naked Silicon Nitride Deep Groove Ceramic Ball Bearing: 6216-SN

Deep Groove, Single Row, Ceramic, Naked, Si3N4
$2,127.75
This product has a minimum quantity of 2
CAD
Specifications:
Attribute nameAttribute value
SeriesSi3N4
SealsNone
Bore (mm)80
D (mm)140
B (mm)26
d1 (mm)101
D2 (mm)127
C (lb)4086
C0 (lb)2979
Nmax (RPM)3710
Weight(lbs)1.22
Code101711
PackageQTY1
UOMEA
C (kN)18.175
C0 (kN)13.25
Ra (mm)2
Da (mm)129
damin (mm)91
kr25
ka0.5
fo15
r (mm)2
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
Construction482F Open
DutyCeramic
