800°C Silicon Nitride Deep Groove Ball Bearing: 6211-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6211-SNF

Deep Groove, Full Complement, Single Row, High Temperature 800 °C Si3N4 Ball Bearing
$715.58
This product has a minimum quantity of 5
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)55
D (mm)100
B (mm)21
d1 (mm)69.1
D2 (mm)89.4
C (lb)2439
C0 (lb)1652
Nmax (RPM)3675
Weight(lbs)0.53
Code101652
PackageQTY1
UOMEA
C (kN)10.85
C0 (kN)7.35
Ra (mm)1.5
Da (mm)91
damin (mm)64
kr25
ka0.5
fo14
r (mm)1.5
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSi3N4
