400°C Zirconium Oxide Deep Groove Ball Bearing: 6210-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6210-ZOF

Deep Groove, Full Complement, Single Row, High Temp 400 C, ZrO2
$356.78
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)50
D (mm)90
B (mm)20
d1 (mm)62.5
D2 (mm)81.6
C (lb)2367
C0 (lb)1571
Nmax (RPM)3570
Weight(lbs)0.77
Code270052
PackageQTY1
UOMEA
C (kN)10.53
C0 (kN)6.99
Ra (mm)1
Da (mm)83
damin (mm)57
kr25
ka0.5
fo14
r (mm)1.1
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesZrO2
