Sealed Zirconium Oxide Deep Groove Ceramic Ball Bearing: 6210-ZO2RS

Sealed Zirconium Oxide Deep Groove Ceramic Ball Bearing: 6210-ZO2RS

Deep Groove, Single Row, Ceramic, Sealed, ZrO2
$354.20
CAD
Specifications:
Attribute nameAttribute value
SeriesZrO2
SealsSeals
Bore (mm)50
D (mm)90
B (mm)20
d1 (mm)62.5
D2 (mm)81.6
C (lb)2367
C0 (lb)1571
Nmax (RPM)5100
Weight(lbs)0.77
Code101641
PackageQTY1
UOMEA
C (kN)10.53
C0 (kN)6.99
Ra (mm)1
Da (mm)83
damin (mm)57
kr25
ka0.5
fo14
r (mm)1.1
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
