400°C Zirconium Oxide Deep Groove Ball Bearing: 6208-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6208-ZOF

Deep Groove, Full Complement, Single Row, High Temp 400 C, ZrO2
$151.44
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)40
D (mm)80
B (mm)18
d1 (mm)52.6
D2 (mm)69.8
C (lb)1963
C0 (lb)1200
Nmax (RPM)4200
Weight(lbs)0.61
Code270049
PackageQTY1
UOMEA
SeriesZrO2
C (kN)8.73
C0 (kN)5.34
Ra (mm)1
Da (mm)73
damin (mm)47
kr25
ka0.5
fo14
r (mm)1.1
SealsNone
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
