800°C Silicon Nitride Deep Groove Ball Bearing: 6206-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6206-SNF

Deep Groove, Full Complement, Single Row, High Temperature 800 °C Si3N4 Ball Bearing
$196.35
This product has a minimum quantity of 5
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)30
D (mm)62
B (mm)16
d1 (mm)40.4
D2 (mm)54.1
C (lb)1096
C0 (lb)635
Nmax (RPM)6370
Weight(lbs)0.18
Code270045
PackageQTY1
UOMEA
C (kN)4.875
C0 (kN)2.825
Ra (mm)1
Da (mm)56.4
damin (mm)35.6
kr25
ka0.5
fo14
r (mm)1
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSi3N4
