Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6206-SC2RS

Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6206-SC2RS

Deep Groove, Single Row, Ceramic, Sealed, SiC
$207.90
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
SeriesSiC
SealsSeals
Bore (mm)30
D (mm)62
B (mm)16
d1 (mm)40.4
D2 (mm)54.1
C (lb)877
C0 (lb)508
Nmax (RPM)7800
Weight(lbs)0.18
Code101590
PackageQTY1
UOMEA
C (kN)3.9
C0 (kN)2.26
Ra (mm)1
Da (mm)56.4
damin (mm)35.6
kr25
ka0.5
fo14
r (mm)1
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
