1200°C Silicon Carbide Deep Groove Ball Bearing: 6020-SCF

1200°C Silicon Carbide Deep Groove Ball Bearing: 6020-SCF

Deep Groove, Full Complement, Single Row, High Temperature 1200 °C SiC Ball Bearing
$3,847.89
This product has a minimum quantity of 3
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction2192F Open
Shaft Size100mm
D (mm)150
B (mm)24
d1 (mm)110
D2 (mm)138
C (lb)2707
C0 (lb)2437
Nmax (RPM)2226
Weight(lbs)1.1
Code101433
PackageQTY1
UOMEA
Bore (mm)100
C (kN)12.04
C0 (kN)10.84
Ra (mm)1.5
Da (mm)143
damin (mm)107
kr25
ka0.25
fo16
r (mm)1.5
Clearance0.0005"
Tmax (F)2192
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSiC
MaterialSiC
Designed to handle a combination of radial and axial forces at a range of speeds, temperatures, and environments for an extended period with minimal friction. Operation above the continuous duty temperature will reuslt in a loss of clearnce and reduce bearing life.
