400°C Zirconium Oxide Deep Groove Ball Bearing: 6015-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6015-ZOF

Deep Groove, Full Complement, Single Row, High Temp 400 C, ZrO2
$639.10
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)75
D (mm)115
B (mm)20
d1 (mm)87.9
D2 (mm)105
C (lb)2671
C0 (lb)2259
Nmax (RPM)2814
Weight(lbs)1.06
Code101369
PackageQTY1
UOMEA
C (kN)11.88
C0 (kN)10.05
Ra (mm)1
Da (mm)109
damin (mm)81
kr25
ka0.25
fo16
r (mm)1.1
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesZrO2
