Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6014-SC2RS

Sealed Silicon Carbide Deep Groove Ceramic Ball Bearing: 6014-SC2RS

Deep Groove, Single Row, Ceramic, Sealed, SiC
$1,095.96
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
SeriesSiC
SealsSeals
Bore (mm)70
D (mm)110
B (mm)20
d1 (mm)82.9
D2 (mm)99.9
C (lb)1713
C0 (lb)1389
Nmax (RPM)4260
Weight(lbs)0.53
Code101350
PackageQTY1
UOMEA
C (kN)7.62
C0 (kN)6.18
Ra (mm)1
Da (mm)104
damin (mm)76
kr25
ka0.25
fo16
r (mm)1.1
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
DutyCeramic
Construction482F Seals Ceramic
