800°C Silicon Nitride Deep Groove Ball Bearing: 6011-SNF

800°C Silicon Nitride Deep Groove Ball Bearing: 6011-SNF

Deep Groove, Full Complement, Single Row, High Temp 800 C,Si3N4
$410.66
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction1472F Open
Bore (mm)55
D (mm)90
B (mm)18
d1 (mm)66.3
D2 (mm)81.5
C (lb)1591
C0 (lb)1191
Nmax (RPM)4410
Weight(lbs)0.33
Code270023
PackageQTY1
UOMEA
SeriesSi3N4
C (kN)7.075
C0 (kN)5.3
Ra (mm)1
Da (mm)84
damin (mm)61
kr25
ka0.25
fo15
r (mm)1.1
SealsNone
Clearance0.0005"
Tmax (F)1472
Tmin (F)-112
DutyHigh Temperature
