Naked Silicon Carbide Deep Groove Ceramic Ball Bearing: 6008-SC

Naked Silicon Carbide Deep Groove Ceramic Ball Bearing: 6008-SC

Deep Groove, Single Row, Ceramic, Naked, SiC
$225.87
This product has a minimum quantity of 3
CAD
Specifications:
Attribute nameAttribute value
SeriesSiC
SealsNone
Bore (mm)40
D (mm)68
B (mm)15
d1 (mm)49.3
D2 (mm)61.1
C (lb)751
C0 (lb)517
Nmax (RPM)7200
Weight(lbs)0.17
Code101278
PackageQTY1
UOMEA
C (kN)3.34
C0 (kN)2.3
Ra (mm)1
Da (mm)63.4
damin (mm)44.6
kr25
ka0.25
fo15
r (mm)1
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
Construction482F Open
DutyCeramic
