Naked Silicon Nitride Deep Groove Ceramic Ball Bearing: 6005-SN

Naked Silicon Nitride Deep Groove Ceramic Ball Bearing: 6005-SN

Deep Groove, Single Row, Ceramic, Naked, Si3N4
$154.00
CAD
Specifications:
Attribute nameAttribute value
SeriesSi3N4
SealsNone
Bore (mm)25
D (mm)47
B (mm)12
d1 (mm)29.7
D2 (mm)42.2
C (lb)568
C0 (lb)329
Nmax (RPM)12600
Weight(lbs)0.07
Code101253
PackageQTY1
UOMEA
C (kN)2.525
C0 (kN)1.4625
Ra (mm)0.6
Da (mm)43.8
damin (mm)28.2
kr25
ka0.25
fo14
r (mm)0.6
Clearance0.0005"
Tmax (F)482
Tmin (F)-94
Construction482F Open
DutyCeramic
