1200°C Silicon Carbide Deep Groove Ball Bearing: 6002-SCF

1200°C Silicon Carbide Deep Groove Ball Bearing: 6002-SCF

Deep Groove, Full Complement, Single Row, High Temperature 1200 °C SiC Ball Bearing
$110.08
This product has a minimum quantity of 3
EA

checkbox icon This item typically ship in 1-4 weeks.

checkbox icon Item listed as "Request For Quote" (RFQ) usually ship in 3-6 week

CAD
Specifications:
Attribute nameAttribute value
Construction2192F Open
Shaft Size15mm
D (mm)32
B (mm)9
d1 (mm)18.7
D2 (mm)28.2
C (lb)252
C0 (lb)128
Nmax (RPM)11340
Weight(lbs)0.03
Code101225
PackageQTY1
UOMEA
Bore (mm)15
C (kN)1.12
C0 (kN)0.57
Ra (mm)0.3
Da (mm)30
damin (mm)17
kr25
ka0.25
fo14
r (mm)0.3
Clearance0.0005"
Tmax (F)2192
Tmin (F)-112
DutyHigh Temperature
SealsNone
SeriesSiC
MaterialSiC
Designed to handle a combination of radial and axial forces at a range of speeds, temperatures, and environments for an extended period with minimal friction. Operation above the continuous duty temperature will reuslt in a loss of clearnce and reduce bearing life.
