400°C Zirconium Oxide Deep Groove Ball Bearing: 6001-ZOF

400°C Zirconium Oxide Deep Groove Ball Bearing: 6001-ZOF

Deep Groove, Full Complement, Single Row, High Temp 400 C, ZrO2
$56.14
This product has a minimum quantity of 5
CAD
Specifications:
Attribute nameAttribute value
Construction752F Open
Bore (mm)12
D (mm)28
B (mm)8
d1 (mm)15.2
D2 (mm)24.8
C (lb)344
C0 (lb)162
Nmax (RPM)13440
Weight(lbs)0.04
Code270005
PackageQTY1
UOMEA
SeriesZrO2
C (kN)1.53
C0 (kN)0.72
Ra (mm)0.3
Da (mm)26
damin (mm)14
kr25
ka0.25
fo13
r (mm)0.3
SealsNone
Clearance0.0005"
Tmax (F)752
Tmin (F)-112
DutyHigh Temperature
