Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF316SNT600-394P

Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF316SNT600-394P

4-Bolt, NT600, Split Steel
$1,876.20
CAD
MANUAL
Specifications:
Attribute nameAttribute value
ConstructionSplit 4-Bolt Flange
Tmax (F)500
Bore (in)3.968
A (in)3.175
B (in)9.843
C (in)3.242
D (in)7.717
F (in)1.22
H (in)1.63
J (in)0.565
L (in)5.356
Bearing InsertSSP316-NT6-394
Static (lb)6267
Weight(lbs)37
Code440084
PackageQTY1
UOMEA
SeriesSSP
ShaftDia (in)3.938
Tmin (F)-400
MaterialNT600
10 RPM (lb)6267
50 RPM (lb)6267
100 RPM (lb)1253
200 RPM (lb)1253
Max Cap Load (lb)5100
Max Thrust Load (lb)627
Tservice (F)500
Shaft size3 15/16"
