Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF215SNT600-75P

Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF215SNT600-75P

4-Bolt, NT600, Split Steel
$1,332.00
CAD
MANUAL
Specifications:
Attribute nameAttribute value
ConstructionSplit 4-Bolt Flange
Tmax (F)500
Bore (in)2.976
A (in)2.591
B (in)7.874
C (in)2.91
D (in)6
F (in)0.787
H (in)0.945
J (in)0.469
L (in)4.84
Bearing InsertSSP215-NT6-75
Static (lb)3837
Weight(lbs)20
Code440076
PackageQTY1
UOMEA
SeriesSSP
ShaftDia (in)2.953
Tmin (F)-400
MaterialNT600
10 RPM (lb)3837
50 RPM (lb)3837
100 RPM (lb)3837
200 RPM (lb)767
Max Cap Load (lb)3837
Max Thrust Load (lb)384
Tservice (F)500
Shaft size75mm
