Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF207SNT600-35P

Split 4-Bolt Flange NT600 Composite Sleeve Bearing: 4BF207SNT600-35P

4-Bolt, NT600, Split Steel
$765.60
CAD
MANUAL
Specifications:
Attribute nameAttribute value
ConstructionSplit 4-Bolt Flange
Tmax (F)500
Bore (in)1.398
A (in)1.289
B (in)4.66
C (in)1.393
D (in)3.622
F (in)0.512
H (in)0.61
J (in)0.54
L (in)2.339
Bearing InsertSSP207-NT6-35
Static (lb)893
Weight(lbs)4
Code440052
PackageQTY1
UOMEA
SeriesSSP
ShaftDia (in)1.378
Tmin (F)-400
MaterialNT600
10 RPM (lb)893
50 RPM (lb)893
100 RPM (lb)893
200 RPM (lb)893
Max Cap Load (lb)893
Max Thrust Load (lb)89
Tservice (F)500
Shaft size35mm
